ALCK6150X1000
ALLES CNC
CNC lathe is an automatic CNC lathe with high precision and high efficiency. Equipped with a multi-station turret or a power turret, the CNC turn-mill machine has a wide range of processing performance。
Super low price CNC lathe ALCK6150
Metal CNC lathes are easy to operate, safe to protect, novel and beautiful in appearance, easy to maintain and easy to maintain.
CNC lathe processing has strong adaptability to processing objects, adapts to the characteristics of single-piece production of molds and other products, and provides suitable processing methods for mold manufacturing;
Equipment configuration and parameters
| Item | Unit | ALCK6150*1000 |
| Max swing over bed | mm | Φ500 |
| Maximum swing over slide | mm | Φ290 |
| Maximum cutting diameter | mm | Φ500 |
| Maximum processing length | mm | 1000 |
| X/Z axis maximum stroke | mm | 300/1000 |
| X/Z axis minimum displacement unit | mm | 0.001 |
| Spindle hole diameter | mm | F82 |
| Spindle speed limit | rpm | 150-2000/60-1600 |
| Main motor power (frequency conversion) | kW | 7.5 |
| Frequency converter | kW | 7.5 |
| X/Z axis | N.m | 5/7.5 |
| X/Z axis rapid traverse speed | m/min | 6/8 |
| Tool bar size | mm | 25*25 |
| Repeated positioning accuracy of tool post | mm | ≤0.004 |
| Diameter of tailstock sleeve | mm | Φ65 |
| Tailstock sleeve stroke | mm | 130 |
| Electricity demand (power/current) | kW/A | 15kW/20A |
| Weight | Kg | 2500 |
| Machine size | mm | 3030*1600*2050 |
Super low price CNC lathe ALCK6150x1000 With Siemens CNC system
High speed and precision are the eternal goals of CNC lathe 3 axis development. With the rapid development of science and technology, the speed of replacement of electro mechanical products is accelerated, and the requirements for the precision and surface quality of parts processing are also higher and higher.
In order to meet the needs of this complex and changeable market, the current automatic CNC lathe is developing in the direction of high-speed cutting, dry cutting and quasi-dry cutting, and the machining accuracy is constantly improving.
On the other hand, the successful application of electric spindles and linear motors, ceramic ball bearings, low-temperature high-speed ball screw pairs with high-precision large-lead hollow internal cooling and strong ball nut cooling, and linear guide pairs with ball cages and other machine tool functional components The market launch also creates conditions for the development of flat bed CNC lathe to high speed and precision.
Horizontal CNC Lathe is used for turning of long axial dimensions or small disc parts.
Horizontal CNC Lathe can be further divided into economical CNC lathes, ordinary CNC lathes and turning machining centers by function.
CNC lathe is an automatic CNC lathe with high precision and high efficiency. Equipped with a multi-station turret or a power turret, the CNC turn-mill machine has a wide range of processing performance。
Super low price CNC lathe ALCK6150
Metal CNC lathes are easy to operate, safe to protect, novel and beautiful in appearance, easy to maintain and easy to maintain.
CNC lathe processing has strong adaptability to processing objects, adapts to the characteristics of single-piece production of molds and other products, and provides suitable processing methods for mold manufacturing;
Equipment configuration and parameters
| Item | Unit | ALCK6150*1000 |
| Max swing over bed | mm | Φ500 |
| Maximum swing over slide | mm | Φ290 |
| Maximum cutting diameter | mm | Φ500 |
| Maximum processing length | mm | 1000 |
| X/Z axis maximum stroke | mm | 300/1000 |
| X/Z axis minimum displacement unit | mm | 0.001 |
| Spindle hole diameter | mm | F82 |
| Spindle speed limit | rpm | 150-2000/60-1600 |
| Main motor power (frequency conversion) | kW | 7.5 |
| Frequency converter | kW | 7.5 |
| X/Z axis | N.m | 5/7.5 |
| X/Z axis rapid traverse speed | m/min | 6/8 |
| Tool bar size | mm | 25*25 |
| Repeated positioning accuracy of tool post | mm | ≤0.004 |
| Diameter of tailstock sleeve | mm | Φ65 |
| Tailstock sleeve stroke | mm | 130 |
| Electricity demand (power/current) | kW/A | 15kW/20A |
| Weight | Kg | 2500 |
| Machine size | mm | 3030*1600*2050 |
Super low price CNC lathe ALCK6150x1000 With Siemens CNC system
High speed and precision are the eternal goals of CNC lathe 3 axis development. With the rapid development of science and technology, the speed of replacement of electro mechanical products is accelerated, and the requirements for the precision and surface quality of parts processing are also higher and higher.
In order to meet the needs of this complex and changeable market, the current automatic CNC lathe is developing in the direction of high-speed cutting, dry cutting and quasi-dry cutting, and the machining accuracy is constantly improving.
On the other hand, the successful application of electric spindles and linear motors, ceramic ball bearings, low-temperature high-speed ball screw pairs with high-precision large-lead hollow internal cooling and strong ball nut cooling, and linear guide pairs with ball cages and other machine tool functional components The market launch also creates conditions for the development of flat bed CNC lathe to high speed and precision.
Horizontal CNC Lathe is used for turning of long axial dimensions or small disc parts.
Horizontal CNC Lathe can be further divided into economical CNC lathes, ordinary CNC lathes and turning machining centers by function.
