ALCK6140x750
ALLES CNC
Horizontal CMC lathe machine and milling compound machine equipped with multi-station turret or dynamic turret has a wide range of processing performance.
ALCK6140x750 CNC Lathe Inspection
1.CNC lathe which has good rigidity and strong anti-vibration ability; the guideway surface is quenched by medium frequency to ensure long life, high precision and good retention;
2. CNC lathe machine upper opening of the head box body is a lock style, with strong structural rigidity,
3. X-direction and Z-direction adopt precision ground ball screw pair, and use special angular
4. CNC lathe turning base adopts the integral base, lost foam casting, and the appearance is flat and beautiful;
5. Mini metal lathe electric tool holder, fast and convenient tool change (also can be equipped with arranging tool holder);
Device parameters
| Model | ALCK6140x750 | |
| Processing capacity | Maximum turning diameter of bed | 400mm |
| Maximum turning diameter on the tool post | 220mm | |
| Center distance | 750mm | |
| Rail width | 360mm | |
| X stroke | 250mm | |
| Z-stroke | 900mm | |
| Headstock | Spindle hole diameter | 52mm |
| Spindle end type | ISO-C6 | |
| Taper of spindle bore | MT6 | |
| Spindle speed range | Gear two-speed 50-1600rpm/single axis 2200rpm | |
| Skateboard | (number of stages) | (optional) |
| Fast moving speed of carriage | X/Z:5/8m/min | |
| Repeatability | Z:0.013mm X:0.012mm | |
| Number of tools | 4 | |
| Tailstock | Tool change time | 1sec |
| Diameter of tailstock sleeve | 65mm | |
| Taper of tailstock sleeve | MT4 | |
| Motor | Maximum stroke of tailstock sleeve | 120mm |
| Servo main motor power | 5.5KW | |
| Cooling pump | 125W | |
| PACKING(L*W*H) | 2350*1400*1800mm | |
| WEIGHT(N.W/G.W) | 1550/1650kg | |
ALCK6140X750 CNC Lathe Machine
1. The processing quality of the CNC lathe machine is stable and the precision is high.
2. The mini CNC lathe can be linked with multiple coordinates and can process parts with complex shapes.
3. The horizontal CNC lathe machine is processed according to the programmed program. If the design of the part changes, it is only necessary to modify the program, which saves time and effort.
4. The mini lathe CNC has a high degree of automation and reduces the manual labor.
CNC turning machine is suitable to process all kinds of small and middle-sized shaft and plate work piece,and could also turn various threads,circle arc,circular cone,inside and outside surface of revolved body.
Horizontal CMC lathe machine and milling compound machine equipped with multi-station turret or dynamic turret has a wide range of processing performance.
