ALSM203
ALLES CNC
Swiss automatic lathe feed material through a guide bushing, cutting the material close to the fulcrum, no matter how long the workpiece is. This makes it particularly effective for long and slender turned parts.
swiss type lathe can handle mass production in a short time. In fact, swiss cnc machines have shorter cycle times than most other CNC machines. This is because of the multi-axis machining capability and bar feed method. Thanks to the multi-axis capability, swiss cnc machines are able to perform several operations at once, such as turning, threading and milling. The sliding head feed mechanism also reduces cycle time.
| ltems | ALSM203 | ||
| mechanic | System | FANUC Oi | SYNTEC |
| Max.RPM | Main10,000min-1/ | Main6,000min-1/8,000min-1 | |
| Max Tuning Diameter | ф20mm | ||
| Main Spindle Stroke | 260mm | ||
| Tools | O.D Tools | 6X[口12x12] | |
| I.N Tools | 5X[ф25-ER16] | ||
| Cross Driven Tools(integration) | 4X[ER16] | ||
| Motors | Main | 2.2/3.7KW | 4.4KW |
| Cross | 1KW | 0.75KW | |
| Drive | 0.75KW | ||
| Coolant | 0.4KW | ||
Others | Central Height | 1,000mm | |
| Weight | 2800Kg | ||
| Thesize(L*W*H) | 2135*1366*1670mm | ||
The guide bush is the heart of a Swiss screw machine. Along with the chucking collet, it holds the workpiece in place during the machining process. The bar stock only exposes the part that is machined.
This Swiss screw machine design decreases deflection and improves accuracy. Using the wrong size guide bushing will result in concentricity errors. The material of these parts affects the interaction with the bar stock and thus influences the ability to hold and stabilize the workpiece.
Swiss automatic lathe can process almost any material. It can machine common metals such as aluminum, brass, carbon, steel, copper, etc. Swiss automatic lathe can also cut special materials such as nickel, nylon, plastic, titanium, stainless steel, etc.
Swiss automatic lathe feed material through a guide bushing, cutting the material close to the fulcrum, no matter how long the workpiece is. This makes it particularly effective for long and slender turned parts.
swiss type lathe can handle mass production in a short time. In fact, swiss cnc machines have shorter cycle times than most other CNC machines. This is because of the multi-axis machining capability and bar feed method. Thanks to the multi-axis capability, swiss cnc machines are able to perform several operations at once, such as turning, threading and milling. The sliding head feed mechanism also reduces cycle time.
| ltems | ALSM203 | ||
| mechanic | System | FANUC Oi | SYNTEC |
| Max.RPM | Main10,000min-1/ | Main6,000min-1/8,000min-1 | |
| Max Tuning Diameter | ф20mm | ||
| Main Spindle Stroke | 260mm | ||
| Tools | O.D Tools | 6X[口12x12] | |
| I.N Tools | 5X[ф25-ER16] | ||
| Cross Driven Tools(integration) | 4X[ER16] | ||
| Motors | Main | 2.2/3.7KW | 4.4KW |
| Cross | 1KW | 0.75KW | |
| Drive | 0.75KW | ||
| Coolant | 0.4KW | ||
Others | Central Height | 1,000mm | |
| Weight | 2800Kg | ||
| Thesize(L*W*H) | 2135*1366*1670mm | ||
The guide bush is the heart of a Swiss screw machine. Along with the chucking collet, it holds the workpiece in place during the machining process. The bar stock only exposes the part that is machined.
This Swiss screw machine design decreases deflection and improves accuracy. Using the wrong size guide bushing will result in concentricity errors. The material of these parts affects the interaction with the bar stock and thus influences the ability to hold and stabilize the workpiece.
Swiss automatic lathe can process almost any material. It can machine common metals such as aluminum, brass, carbon, steel, copper, etc. Swiss automatic lathe can also cut special materials such as nickel, nylon, plastic, titanium, stainless steel, etc.
